SWITCH ACTUATOR, 6-GANG / BLINDS ACTUATOR, 3-GANG

rail mounting device, 4 rail units
with manual electronic operation and LED status indication
Project design and commissioning with ETS5 or a more recent version
ETS product family: Output
Product type: Binary output

23006 1S R

Intended use

  • Switching of electrical loads with floating contacts
  • Switching of electrically-driven blinds, shutters, awnings and similar hangings
  • Mounting on DIN rail according to EN¬†60715 in distribution boxes



Product characteristics

  • Outputs can be operated manually, construction site mode
  • Feedback in manual mode and in bus mode
  • Disabling of individual outputs manually or via bus
  • Central functions
  • Cyclical monitoring
  • KNX Data¬†Secure compatible with¬†ETS¬†5.7.3 or higher
  • Can be updated with the ETS¬†Service¬†App



Characteristics switching operation

  • Operation as NO or NC contacts
  • Feedback function
  • Logic operation and forcing function
  • Central switching function with collective feedback
  • Time functions: switch-on delay, switch-off delay, staircase lighting timer with pre-warning function
  • Scene function
  • Operating hours counter



Characteristics blinds operation

  • Suitable for 230¬†V¬†AC motors
  • Operation modes ‚ÄėBlind with slats‚Äô, ‚ÄėShutter/awning‚Äô, ‚ÄėVentilation¬†flap/skylight‚Äô
  • Blind/shutter position directly controllable
  • Slat position directly controllable
  • Feedback of movement status, blind/shutter position and slat position
  • Cyclical feedback during movement
  • Forced position through higher-level controller
  • Safety function: rain alarm, frost alarm, 3 independent wind alarms
  • Sun protection function with auto Heating/Cooling
  • Scene function

The total current of two adjacent outputs must not exceed 20 A.

Technical data

Ambient temperature: ‚ąí5 … +45 ¬įC
Storage/transport temperature: ‚ąí25 … +70 ¬įC
KNX
    KNX medium: TP 256
¬†¬†¬†¬†Rated voltage KNX: DC 21 … 32 V SELV
¬†¬†¬†¬†Current consumption KNX: 4 … 18 mA
Outputs
    Switching voltage: AC 250 V ~
¬†¬†¬†¬†Switching current AC1 (cos Ōē > 0.8): 16 A
    Fluorescent lamps: 16 AX
Current carrying capacity
¬†¬†¬†¬†Neighbouring outputs: ő£ 20 A
Loads per output
    Ohmic load: 3000 W
¬†¬†¬†¬†Capacitive load: 16 A / 140 ¬ĶF
    Motors: 1380 VA
¬†¬†¬†¬†Switch-on current 200 ¬Ķs: max. 800 A
    Switch-on current 20 ms: max. 165 A
Lamp loads 230 V
Incandescent lamps: 2300 W
HV halogen lamps: 2300 W
HV LED lamps: max. 400 W
LV halogen lamps with
    electronic transformers: 1500 W
    inductive transformers: 1200 VA
Fluorescent lamps T5/T8
    non-compensated: 1000 W
¬†¬†¬†¬†parallel compensated: 1160 W / 140 ¬ĶF
¬†¬†¬†¬†lead-lag circuit: 2300 W / 140 ¬ĶF
Compact fluorescent lamps
    non-compensated: 1000 W
¬†¬†¬†¬†parallel compensated: 1160 W / 140 ¬ĶF
Mercury vapour lamps
    non-compensated: 1000 W
¬†¬†¬†¬†parallel compensated: 1160 W / 140 ¬ĶF
Mounting width: 72 mm (4 rail units)
Connection, power supply and load
    Connection mode: screw terminals
¬†¬†¬†¬†single wire: 1 x 0.5 … 4 mm¬≤
¬†¬†¬†¬†stranded without ferrule: 1 x 0.5 … 4 mm¬≤
¬†¬†¬†¬†stranded with ferrule: 1 x 0.5 … 2.5 mm¬≤
KNX: KNX bus connection block
