with integrated 1-gang frame LS 990
single device, not suitable for combinations

Intended use

  • Operating loads and displaying the status of systems and information e.g. light switching, dimming, controlling blinds/shutters, temperature and consumption values etc.
  • Measurement and feedback control of the room temperature
  • Installation in flush box with dimensions according to DIN 49073

Product characteristics

  • High resolution IPS colour display
  • Capacitive touchscreen
  • Function of favourites page adjustable (without ETS)
  • Max. 32 operating functions switching, dimming, controlling blinds, value transmitters, calling up light scenes, etc.
  • Integrated room temperature sensor
  • Room temperature control with setpoint value specification
  • Alarm function (optical and/or acoustic)
  • Max. 8 timer functions can be activated and set (depending on time, astronomical clock or random)
  • Integrated proximity and brightness sensor
  • Integrated bus coupling unit
  • Connection of installation buttons or reed contacts possible
  • Commissioning and support of KNX Data Secure with ETS from version 5.7.4
  • Display of room temperature and setpoint temperature
  • External sensor (ref.-no.: FF NTC) can be connected
  • Display of outdoor temperature – with external sensor, e.g. weather station
  • In combination with JUNG Visu Pro software “Multi-Room Control”: music play control, display of music titles, artists, etc.
