Elipson LEGACY 3210

2,989.28 inc V.A.T.

The Elipson Legacy 3210 compact loudspeaker is a 2-way model with a 16.5cm diameter bass/midrange driver and a wide dispersion AMT tweeter.

The Legacy range perfectly embodies the brand’s HIFI know-how! To design this new range, Elipson has taken advantage of the innovations developed in-house for more than 60 years through emblematic models such as the La Religieuse loudspeaker, the 4050 or 1303 model, combined with the modern materials of our time.

The Elipson Legacy 3210 bookshelf speaker is the first model in the Elipson Legacy speaker range. With its compact size, it benefits from the qualities of the superior models: fast, bright, airy and precise sound image, it also offers an articulated and deep bass register, which is rare in this speaker format.



The Legacy 3210 is a 2-way model equipped with a 16.5cm diameter bass/midrange driver and a wide dispersion AMT tweeter.

THE ELIPSON LEGACY

The Legacy range perfectly embodies the Elipson brand’s HIFI know-how. To conceive this new range, we have taken advantage of the innovations developed for more than 60 years in-house through emblematic models such as the Religieuse, the 4050 or the 1303, associated with the modern materials of our time.
Fast, bright, perfect extension of the extreme frequencies, expressiveness of the midrange register, airy and realistic sound image, are all qualities that characterise the Legacy speakers

ELIPSON’S SIGNATURE

The LEGACY 3230 loudspeaker takes up the mythical codes of Elipson loudspeakers with its decoupled sphere, made of silica-filled resin, including the midrange and high frequency drivers. This sphere offers a free propagation of the high and medium frequencies.
An AMT (Air Motion Transformer) tweeter tops the upper part of the sphere and allows to combine lightness, large emissive surface and perfect respect of transients.

A UNIQUE KNOW-HOW

The entire LEGACY range is built around a curved enclosure of varying thickness and is equipped with internal bracing to ensure that the front baffle and rear panel make contact under stress via the magnetic assembly of the bass and midrange drivers

STATE-OF-THE-ART TECHNOLOGY

The aluminium midrange drivers are ceramic surfaced, offering lightness, rigidity and low resonance in perfect harmony with the performance and velocity of the AMT tweeters.

A DOUBLE TERMINAL BLOCK

The LEGACY range is equipped with dual terminal blocks to provide a clean contact and high conductivity rating.
The dual terminal block allows for passive bi-wiring or bi-amping, supplied with high conductivity wire straps in the single wire configuration.

FRENCH MANUFACTURE



The entire LEGACY range is made in Burgundy, about 200 km from Paris, in our production workshops.

A meticulous design and a precious know-how that we are very proud to perpetuate.

Dimensions :

  • W276 x H404 x D360 mm

Weight :

  • 13,9 kg

Finishes :

  • Silver oak or walnut + black satin

Type :

  • Bookshelf speaker 2 way Bass-reflex

Power :

  • 100 W RMS

Drive-units :

  • Mid-woofer : 6.5鈥 aluminium cone with ceramic layer
  • Tweeter Ribbon-AMT

Frequency response :

  • 42-30000 Hz (+/- 3 dB) – 38 kHz @ -5dB

Sensitivity :

  • 88 dB/1W/1m

Nominal impedance :

  • 6 Ohms (Min : 4,9 Ohm @ 175 Hz)

Connectors :

  • Audiophile quality for bi-wiring or bi-amplification

Cut-off frequencies :

  • 2800 Hz

Crossover slopes :

  • High Pass : 18 dB/octave with impedance equalization
  • Low Pass : 12 dB/octave with Notch circuitry

Cabinet :

  • MDF 22-25mm with brace (1) coupling mid-woofer with cabinet structure

Bass-reflex type :

  • Rear ported – Flared shape

1.Loudspeaker
2. Protective cover
3. Gloves
4. Spikes and counter-spikes
5. User Manual

Weight
13.9 kg
Dimensions
27.6 × 36 × 40.4 cm
